Pneumatic & Chemical Hose
QUALITY : SEMSONEX PREMIUM & SUPER
APPLICATION :
- 1) Compressed Air Connection
- 2) Compressed Air Pneumatic Tools & Equipment
- 3) General Water Delivery With Pressure
- 4) Conveing Acid Alikalies With Pressure
- 5) Recommended For All Types Of Pneumatic Tools In
STRUCTURE :
- 1st Layer - Pvc Transparent
- 2nd Layer - Twisted Nylon Yarn
- 3rd Layer - Pvc Transparent
COLOUR :
- Inner Tube - Transparent Sky Blue
- Outer Tube - Transparent Sky Blue
AS PER :
- I.S. 12492 - 1988 TYPE 1-2-3
- I.S. 12585 - 1988 TYPE 1-2
- I.S. 446 TYPE 2 & 3
| CODE | SIZE | SIZE mm + 0.75 mm |
PRESSURE Kg/Cm2 at 25 0 C + 5% |
COIL LENGTH MTR |
||
|---|---|---|---|---|---|---|
| INCH | ID | OD | W.P. | B.P. | ||
| 8 PM | 5/16'' | 8.00 | 15.50 | 35 | 105 | 100 |
| 6 NS | 1/4'' | 6.30 | 12.30 | 30 | 90 | 100 |
| 8 NS | 5/16'' | 8.00 | 14.00 | 30 | 90 | 100 |
| 10 NS | 3/8'' | 9.50 | 15.50 | 27 | 81 | 100 |
| 12 NS | 1/2'' | 12.00 | 19.00 | 21 | 63 | 100 |
| 19 NS | 3/4'' | 19.00 | 27.00 | 20 | 60 | 50 |
| 25 NS | 1'' | 24.50 | 32.50 | 16 | 48 | 50 |
HSN Code : 39172990
GST : 18%
